You can twist, bend and stretch your designs.īecause SharkCAD Pro works with parametric constraints, switching between concepts becomes a piece of cake. With SharkCAD Pro you can also model extremely. You create and edit a mesh model and SharkCAD Pro converts it into a 100% smooth surfaced model, suitable for further editing using solid modelling operations such as blending, chamfering, and shelling as well and exporting to NURBS supported file formats like IGES, SAT and STEP. SharkCAD allows you to snap points parallel to an exisiting line, snap one cylindrical face to another and face snapping will aid in aligning one body to another. Snaps can be given on:īesides giving snaps on your model, you can choose to be given snaps on: You can create rabbet, dado, miters, dovetails, and tongue/groove automatically.īecause you can work with intuitve snaps in SharkCAD, you can work very precisely. SharkCAD comes with standard woodworking joints. Make the walls in your plan 3d with a mouse click. Custom walls allow composite walls to be created showing layers of building materials. 3D solid model editing provides drag and drop ease to changing surfaces.ĭraft floor plans easily with auto-trimming walls. Your 3D design will be turned into a 2D working drawing with one mouse click!Īn intuitive way to interact with planar objects and faces of solids. SharkCAD automatically generates 2D drawing from your model. In this way you will have a lot of freedom of form! Not only side by side, but also with each other and through each other! For example: you can subtract a solid from a double-curved surface or accumalate it to it. With SharkCAD you can draw curves, surfaces and solids. With this flexibility and accuracy, you can use it in almost every stage of your design (from illustration to working drawing). NURBS can describe every shape (from a 2D surface to a 3D double-curved surface) very accurately. With SharkCAD you will draw with real NURBS, a mathemical geometry. For example: if you have changed something in the source file, you can make it up-to-date in your design! You can use the gripper to drag and drop copies and to stretch or modify geometry.īecause SharkCAD uses XRefs, you can refer to external files. It can save you a lot of time!Īn intuitive graphical widget that attaches to your objects allowing you to dynamically move, rotate, and scale objects in 2D or 3D. In SharkCAD, you can edit the tool palettes and create your own ones! Very useful if you use some tools very often and want to have them by hand quickly.
Overig: 3D PDF, FACT, Facet, Text and CGM.3D Oppervlakken: IGES, STL, TrueSpace COB, VDA, WaveFront OBJ, VRML and ViewPoint Media.3D CAD: STEP, ACIS, DWG, DXF and CATIA 4.The export possibilities are also extensive: Other: Surfaces/lines by a text file, surfaces using a point cloud, FACT, facet and Text.Surfaces: IGES, Rhinoceros, 3D Studio, SketchUp (Pro), STL, TrueSpace COB, VDA and WaveFront OBJ.SharkCAD Pro also supports SolidWorks, SolidEdge, NX, X_T ans X_B 3D CAD: STEP, ACIS, DWG, DXF, CATIA 4 and ProE.2D Vector: DWG, DXF, EPS and Adobe Illustrator.
#What is sharks 3d software pdf
#What is sharks 3d software software
SharkCAD contains a lot of import and export possibilities, so it can cooperate with almost every 2D and 3D software package on the market. You can choose from the following types of symbols: SharkCAD contains a very extensive symbol library with over 26,000 3D wire models to refine your design.
This allows you to easily find previously made changes and, where appropriate, make a quick change to it. SharkCAD registrates your design history very accurately in a 'tree model'.
